Cisco 200-301 Exam - Topic 3 Question 60 Discussion

Physical connectivity is implemented between the two Layer 2 switches, and the network connectivity between them must be configured1. Configure an LACP EtherChannel and number it as 1; configure it between switches SW1 and SVV2 using interfaces Ethernet0/0 and Ethernet0/1 on both sides. The LACP mode must match on both ends2 Configure the EtherChannel as a trunk link.3. Configure the trunk link with 802.1 q tags.4. Configure the native VLAN of the EtherChannel as VLAN 15.
A) Explanation: Answer as below configuration: On SW1: conf terminal vlan 15 exit interface range eth0/0 - 1 channel-group 1 mode active exit interface port-channel 1 switchport trunk encapsulation dot1q switchport mode trunk switchport trunk native vlan 15 end copy run start on SW2: conf terminal vlan 15 exit interface range eth0/0 - 1 channel-group 1 mode active exit interface port-channel 1 switchport trunk encapsulation dot1q switchport mode trunk switchport trunk native vlan 15 end copy run start

Cisco 200-301 Exam - Topic 3 Question 60 Discussion

Actual exam question for Cisco's 200-301 exam
Question #: 60
Topic #: 3
[All 200-301 Questions]

Physical connectivity is implemented between the two Layer 2 switches, and the network connectivity between them must be configured

1. Configure an LACP EtherChannel and number it as 1; configure it between switches SW1 and SVV2 using interfaces Ethernet0/0 and Ethernet0/1 on both sides. The LACP mode must match on both ends

2 Configure the EtherChannel as a trunk link.

3. Configure the trunk link with 802.1 q tags.

4. Configure the native VLAN of the EtherChannel as VLAN 15.

Show Suggested Answer Hide Answer
Suggested Answer: A

by Raina at Dec 10, 2022, 09:51 AM

Limited Time Offer

25%

Off

Get Premium 200-301 Questions as Interactive Web-Based Practice Test or PDF

Contribute your Thoughts:

0/2000 characters
Submit Cancel
Deonna
10 months ago
I thought trunk links had to use native VLAN 1 by default?
upvoted 0 times
...
Lai
10 months ago
This config looks solid, nice job!
upvoted 0 times
...
Peter
10 months ago
Wait, why VLAN 15? Seems random.
upvoted 0 times
...
Beckie
11 months ago
Totally agree, but don’t forget to match the LACP modes!
upvoted 0 times
...
Lezlie
11 months ago
LACP EtherChannel is a great way to increase bandwidth!
upvoted 0 times
...
Leota
11 months ago
I recall that we had to use the "channel-group" command for EtherChannel, but I hope I remember the syntax correctly for the interface range.
upvoted 0 times
...
Ming
11 months ago
I feel a bit confused about the native VLAN part. Is it always VLAN 15, or can it be different depending on the scenario?
upvoted 0 times
...
Jeniffer
11 months ago
I think the trunk configuration was similar to a practice question we did last week. We definitely used "switchport trunk encapsulation dot1q" for 802.1Q tagging.
upvoted 0 times
...
Armanda
11 months ago
I remember we practiced configuring EtherChannels, but I'm not sure if I got the LACP mode right. Did we always use "active"?
upvoted 0 times
...
Glenn
