Linux Foundation CKAD Exam - Topic 9 Question 5 Discussion

Exhibit:

Given a container that writes a log file in format A and a container that converts log files from format A to format B, create a deployment that runs both containers such that the log files from the first container are converted by the second container, emitting logs in format B.

Task:

* Create a deployment named deployment-xyz in the default namespace, that:

* Includes a primary

lfccncf/busybox:1 container, named logger-dev

* includes a sidecar Ifccncf/fluentd:v0.12 container, named adapter-zen

* Mounts a shared volume /tmp/log on both containers, which does not persist when the pod is deleted

* Instructs the logger-dev

container to run the command

which should output logs to /tmp/log/input.log in plain text format, with example values:

* The adapter-zen sidecar container should read /tmp/log/input.log and output the data to /tmp/log/output.* in Fluentd JSON format. Note that no knowledge of Fluentd is required to complete this task: all you will need to achieve this is to create the ConfigMap from the spec file provided at /opt/KDMC00102/fluentd-configma p.yaml , and mount that ConfigMap to /fluentd/etc in the adapter-zen sidecar container
